Basic
1,Σ Style A/D conversion at 10 rounds per secnd
2, A/D conversion resolution better than 1/1.000,000
3, 5V load cell excitation voltage and drive up to 4*350 ohm or 8 *700ohm load cell
4, Optical isolation 20mA analogue output
5, Power supply DC9V
6, 6 digits 0.4inch IED display
7, Size: 95x48x110 mm, 0.5kg
Additional:
1. MODLE A: AC110-220V is optional
2. MODLE B: 6 relay outputs,2 optical isolation input
3. MODLE 1: Optical isolation RS232C continually output
4. MODLE 2: Optical isolation RS485 two way signal
Software version
VER2.01 - packing scale
VER2.02 - 3-speed rating scale
VER2.03 - screening scale
VER2.04 - 2-materials, 2-speed batching scale
VER2.05 - 3-materials, 2-speed batching scale
VER2.06 - 4-materials batching scale
VER2.07 - 5-materials batching scale
Specifications
| A/D Converter type | Sigma-Delta |
| Sample rate | 10 times / second (50 times / second optional) |
| Display resolution | 3000.00 |
| Internal resolution | 1000000.00 |
| Load cell excitation | DC 5V |
| Load cell | Up to 4 x 350 Ω or 8 x 700 Ω load cell |
| Display | 6-digit 0.4 inch LED |
| Division | 1/2/5/0.1/0.2/0.5/0.01/0.02/0.05/0.001/0.002/0.005/10/ |
| 20/50/100/200/500/0.10/0.20/0.50/0.010/0.020/0.050 | |
| Power | DC 9V 1A adapter or AC 110-220V 50 Hz |
| Operating temperature | 0℃~40℃ |
| Storage temperature | -25℃~55℃ |
| Relative humidity | 85% RH |
| Size | 95 × 48 × 110 mm |
| Weight | 0.5 kg |
| Signal output | 4-20 mA analog output |
| Options | a) Opto-isolated RS232 or RS485 |
| b) 6 relay outputs with 2 opto-isolated inputs that can be used to control the output of relay #1 and #2 |
Buying Guide
| | |
| | |
| | |
Sensor and Control Co., Ltd. was founded in 2006, mainly engaged in Torque Sensor, Load Cell, Pressure Transducer, Strain Gauges and Weighing Indicators. Since establishment, we insist the guidelines of "Customer Oriented, Quality Focused, Professional Service "All products we supply are environment friendly and has passed RoHS test.
Sensorcon, in accordance with the principle of the introduction of advanced professional ultrasonic gas cleaning, clean Room patches, automatic temperature compensation and detection, high and low temperature testing and thermal experiments, laser welding and printing, CAD design, manufacturing and testing sensor test equipment and production technology ,manufacture all varieties of sensors, high precision, stable performance and also has antiseptic, waterproof, anti-explosion, anti-lightning, etc favored deeply by users.
1.How to place an order ?
Please provide us more details of what you want, such as: application, measurement range, output, accuracy, thread type, electric connector and other related parameters.
2.Does SNCoffer any discount ?
Yes, if you buy large QTY, please contact us, we will give you a big discount.
3.What terms of payment are available ?
We accept T/T, L/C, Trade assurance, Western Union, Paypal, etc.
4.When will you arrange the production ?
We will arrange the production immediately after receiving your payment.
5.How do you ensure good product quality ?
We have a complete quality control system, all of our products are fully checked by IQC, OQC departments
before shipping to our clients.
6.Do you have warranty ?
Yes, we provide 1 year warranty for most of our products. Some products we offer 15month to 24 months warranty.
